デバイス検索エンジンでアダプターを特定できます。
アダプターの選択方法
SUPERPROのソフトを開いてデバイスを選択してください。パッツナンバーを選択するとともに、パッケージも正しく選択しなければなりません。例えば、AT89C51
と AT89C51-P44 は違うタイプです。前のはPLCC44に対応、後ろのはDIP40に対応です。AT89C51-P44を選択された場合、適合のアダプターのナンバーとチップの挿し込み方法をウィンドウ上に表示します。
一部経済的なプログラマーのデバイスリストで必要なチップの名前が見つかれない場合、このサイトのアダプターリストをご利用ください。アダプターの配線でDIP以外のパッケージをサポートしています。高級機種は一対一の配線でプログラマーの内部で自動切換えをしています。
画面上部に表示されるのはアダプターの名前です、パッケージの情報も含んでいます。例えば、PLCC44/D44 はPLCC44のアダプターです。SOIC16/D16はSOIC16のアダプターです。SOIC/SOP/SSOP/TSOPのデバイスにとって、同じピン数のアダプターは数種類があります。この場合は、チップのBODY
WIDTH と PITCH 寸法で適合アダプターは決まります。DIP/SOIC/SOP/SDIPのアダプターは大きなＰｉｎサイズでも小さいピンサイズのデバイスに適合します、Ｐｉｎ数が多くても同様のBODY
WIDTHとPITCHであれば適合します。
高性能プログラマー、例えばSUPERPRO/3000U, SUPERPRO/580U,SUPERPRO/280U,
SUPERPRO/680, SUPERPRO/580,SUPERPRO/V, SUPERPRO/III,
SUPERPRO/8000, SUPERPRO/2000の各ピンに電圧とロジック回路を装着していますから、デバイス専用アダプターを必要としません。すべてのソケットアダプターは1対1の接続で使用できます。これをユニバーサルアダプターといいます。
SUPERPRO/3000U,SUPERPRO/580U,SUPERPRO/280U,SUPERPRO/680,
SUPERPRO580, SUPERPRO/V, SUPERPRO/IIIは48ピン以上のデバイスもPEPピン拡張モジュールと専用のソケットアダプターによって、100ピンまで対応できます。このアダプターもユニバーサルです。
一部の56Pinフラッシュメモリに対応している特別にデザインしたアダプターはPEPピン拡張モジュールが必要ありません。さまざまなデバイスに対応できるように、多種のソケットアダプターモジュールの下層PCB基板を複数種用意しています。
経済的なプログラマー例えばSUPERPRO/280, SUPERPRO/LX, SUPERPRO/Zなどでは最適化ピンドライバーを実装しています。電圧とロジックシグナル回線を全部ではなく、特定なピンで実装しています。これらのピンドライバーに対応しているアダプターは専用で用意しております。例えばPLCC44/D40-2。
上記のアダプター選択方法について、不明点があれば、弊社にご連絡ください。
メールでお問い合わせ
型番の後ろに、「*」が付いている場合、PEPシリーズのアダプタが必要です。
※商品価格について
こちらのメール (info@iczoo.com) 宛にお問い合わせください。
| PLCC |
| Part Number |
Pitch (mm) |
Package |
Device Example |
Type |
Price |
|
| CX2020 |
1.27 |
PLCC20 |
|
OPENTOP |
|
| CX2028 |
1.27 |
PLCC28 |
|
OPENTOP |
|
| CX2032 |
1.27 |
PLCC32 |
|
OPENTOP |
|
| CX2044 |
1.27 |
PLCC44 |
|
OPENTOP |
|
| CX2052 |
1.27 |
PLCC52 |
|
OPENTOP |
|
| CX2068 |
1.27 |
PLCC68 |
|
OPENTOP |
|
| CX2084 |
1.27 |
PLCC84 |
|
OPENTOP |
|
| CX2128 |
1.27 |
PLCC28 |
|
COVER |
|
| CX2132 |
1.27 |
PLCC32 |
|
COVER |
|
| CX2144 |
1.27 |
PLCC44 |
|
COVER |
|
| CX2168 |
1.27 |
PLCC68 |
|
COVER |
|
| CX2232 |
1.27 |
PLCC32 |
|
OPENTOP |
|
| CX2244 |
1.27 |
PLCC44 |
|
OPENTOP |
|
| SA648-B6806 |
1.27 |
PLCC68 |
|
OPENTOP |
|
| DX2020 |
1.27 |
PLCC20 |
|
OPENTOP |
|
| DX2032 |
1.27 |
PLCC32 |
|
OPENTOP |
|
| DX2028 |
1.27 |
PLCC28 |
|
OPENTOP |
|
| DX2084 |
1.27
|
PLCC84 |
|
OPENTOP |
|
| QFN |
| Part
Number |
Pitch
(mm) |
Package |
Device
Example |
Type |
Price |
|
| CX4000 |
1 |
QFN6 |
|
COVER |
|
| CX4001 |
0.5 |
QFN8 |
|
COVER |
|
| CX4002 |
0.5 |
QFN8 |
|
COVER |
|
| CX4003 |
0.65 |
QFN8 |
|
COVER |
|
| CX4004 |
0.8 |
QFN8 |
|
COVER |
|
| CX4005 |
1.27 |
QFN8 |
|
OPENTOP |
|
| CX4006 |
1.27 |
QFN8 |
|
OPENTOP |
|
| CX4007 |
0.5 |
QFN10 |
|
COVER |
|
| CX4008 |
0.5 |
QFN16 |
|
COVER |
|
| CX4009 |
0.8 |
QFN16 |
|
COVER |
|
| CX4010 |
0.65 |
QFN16 |
|
COVER |
|
| CX4011 |
0.5 |
QFN20 |
|
COVER |
|
| CX4012 |
0.5 |
QFN24 |
|
COVER |
|
| CX4013 |
0.5 |
QFN28 |
|
COVER |
|
| CX4014 |
0.65 |
QFN28 |
|
COVER |
|
| CX4015 |
0.5 |
QFN32 |
|
COVER |
|
| CX4016 |
0.65 |
QFN32 |
|
COVER |
|
| CX4017 |
0.5 |
QFN40 |
|
COVER |
|
| CX4018 |
0.5 |
QFN44 |
|
COVER |
|
| CX4019 |
0.65 |
QFN44 |
|
COVER |
|
| CX4020 |
0.65 |
QFN44 |
|
COVER |
|
| CX4021 |
0.5 |
QFN48 |
|
COVER |
|
| CX4022 |
0.5 |
QFN56 |
|
COVER |
|
| CX4023 |
0.5 |
QFN64 |
|
COVER |
|
| CX4024 |
1.27 |
QFN8 |
|
COVER |
|
| CX4025 |
0.65 |
QFN20 |
|
COVER |
|
| CX4026 |
0.4 |
QFN68 |
|
COVER |
|
| CX4027 |
0.5 |
QFN48 |
|
COVER |
|
| CX4028 |
0.5 |
QFN68 |
|
COVER |
|
| CX4029 |
0.5 |
QFN36 |
|
COVER |
|
| CX4060 |
0.5 |
QFN32 |
|
OPENTOP |
|
| CX4061 |
0.65 |
QFN32 |
|
OPENTOP |
|
| DX4015 |
0.65 |
QFN32 |
|
OPENTOP |
|
| SOIC/SOP/SON/SOJ/TSSOP/SSOP/PSOP/TSOP |
| Part
Number |
Pitch
(mm) |
Package |
Device
Example |
Type |
Price |
|
| CX1000 |
0.65 |
TSOP24 |
|
OPENTOP |
|
| CX1001 |
0.65 |
TSOP28 |
|
OPENTOP |
|
| CX1002 |
0.5 |
TSOP32 |
|
OPENTOP |
|
| CX1003 |
0.5 |
TSOP32 |
|
OPENTOP |
|
| CX1004 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| CX1005 |
0.5 |
TSOP40 |
|
COVER |
|
| CX1006 |
0.5 |
TSOP40 |
|
OPENTOP |
|
| CX1007 |
0.5 |
TSOP48 |
|
COVER |
|
| CX1008 |
0.4 |
TSOP48 |
|
OPENTOP |
|
| CX1009 |
0.4 |
TSOP52 |
|
OPENTOP |
|
| CX1010 |
0.8 |
TSOP54 |
|
OPENTOP |
|
| CX1011 |
0.5 |
TSOP56 |
|
OPENTOP |
|
| CX1012 |
0.5 |
TSSOP44 |
|
OPENTOP |
|
| CX1013 |
0.5 |
TSSOP64 |
|
OPENTOP |
|
| CX1014 |
1.27 |
PSOP44 |
|
OPENTOP |
|
| CX1015 |
0.65 |
SOP8 |
|
OPENTOP |
|
| CX1016 |
1.27 |
SOP16 |
|
OPENTOP |
|
| CX1017 |
1.27 |
SOP16 |
|
COVER |
|
| CX1018 |
1.27 |
SOP28 |
|
|
|
| CX1019 |
1.27 |
SOP32 |
|
COVER |
|
| CX1020 |
1.27 |
SOP32 |
|
OPENTOP |
|
| CX1021 |
1.27 |
SOP32 |
|
OPENTOP |
|
| CX1022 |
1.27 |
SOP40 |
|
COVER |
|
| CX1023 |
0.4 |
SSOP24 |
|
|
|
| CX1024 |
0.55 |
SSOP28 |
|
COVER |
|
| CX1025 |
0.635 |
SSOP28 |
|
OPENTOP |
|
| CX1026 |
0.65 |
SSOP34 |
|
OPENTOP |
|
| CX1027 |
0.65 |
SSOP44 |
|
OPENTOP |
|
| CX1028 |
0.635 |
SSOP48 |
|
COVER |
|
| CX1029 |
0.8 |
SSOP56 |
|
COVER |
|
| CX1030 |
1.27 |
SOIC16 |
|
COVER |
|
| CX1031 |
1.27 |
SOIC20 |
|
COVER |
|
| CX1032 |
1.27 |
SOIC20 |
|
OPENTOP |
|
| CX1033 |
1.27 |
SOIC28 |
|
COVER |
|
| CX1034 |
1.27 |
SOIC32 |
|
COVER |
|
| CX1035 |
1.27 |
SOIC32 |
|
COVER |
|
| CX1036 |
1.27 |
SOIC32 |
|
OPENTOP |
|
| CX1037 |
1.016 |
SOIC34 |
|
COVER |
|
| CX1038 |
1.27 |
SOJ32 |
|
INSERT |
|
| CX1039 |
1.27 |
SOJ44 |
|
INSERT |
|
| CX1040 |
0.4 |
SON46 |
|
OPENTOP |
|
| CX1042 |
0.5 |
USOP48 |
|
OPENTOP |
|
| CX1043 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| CX1044 |
1.27 |
SOIC8 |
|
OPENTOP |
|
| CX1044-1 |
1.27 |
SOIC8 |
|
OPENTOP |
|
| CX1045 |
1.27 |
SOP8 |
|
OPENTOP |
|
| CX1046 |
0.8 |
TSOP54 |
|
OPENTOP |
|
| CX1047 |
0.8 |
SSOP32 |
|
OPENTOP |
|
| CX1048 |
1.27 |
SOP8 |
|
OPENTOP |
|
| CX1049 |
0.5 |
TSSOP44 |
|
OPENTOP |
|
| CX1050 |
1.27 |
SOIC8 |
|
OPENTOP |
|
| CX1051 |
0.5 |
uSOP10 |
|
OPENTOP |
|
| CX1052 |
0.65 |
SOP32 |
|
OPENTOP |
|
| CX1053 |
0.5 |
TSOP32 |
|
OPENTOP |
|
| CX1054 |
0.635 |
SSOP56 |
|
COVER |
|
| CX1055 |
0.5 |
TSOP56 |
|
OPENTOP |
|
| CX1056 |
0.8 |
SSOP42 |
|
OPENTOP |
|
| CX1057 |
0.8 |
SSOP70 |
|
OPENTOP |
|
| CX1059 |
0.65 |
TSOP8 |
|
OPENTOP |
|
| DX1002 |
0.5 |
TSOP32 |
|
OPENTOP |
|
| DX1055 |
0.5 |
TOSP56 |
|
OPENTOP |
|
| DX1004 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| DX1011 |
0.5 |
TSOP56 |
|
OPENTOP |
|
| DX1033-1 |
1.27 |
SOIC28 |
|
COVER |
|
| DX1043 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| DX1044-1 |
1.27 |
SOIC8 |
|
OPENTOP |
|
| DX1045-1 |
1.27 |
SOIC8 |
|
OPENTOP |
|
| DX1059 |
0.7 |
TSOP8 |
|
OPENTOP |
|
| DX1072-1 |
1.27 |
SOIC16 |
|
OPENTOP |
|
| EX1004 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| SB247-B4806 |
0.5 |
TSOP48 |
|
OPENTOP |
|
| SA715 |
1.27 |
SOIC32 |
|
OPENTOP |
|
| DX1014 |
1.27 |
PSOP44 |
|
OPENTOP |
|
| DX1036#1 |
1.27 |
SOIC28 |
|
OPENTOP |
|
| DX1045#1 |
1.27 |
SOP8 |
|
OPENTOP |
|
| SDIP/QIP |
| Part
Number |
Pitch
(mm) |
Package |
Device
Example |
Type |
Price |
|
| CX0001 |
2.54 |
ZIF48 |
|
ZIF |
|
| CX0032 |
1.778 |
SDIP32 |
|
ZIF |
|
| CX0042 |
1.778 |
SDIP42 |
|
ZIF |
|
| CX0048 |
1.778 |
SDIP48 |
|
INSERT |
|
| CX0056 |
1.778 |
SDIP56 |
|
ZIF |
|
| CX0064 |
1.778 |
SDIP64 |
|
ZIF |
|
| CX0090 |
1.27 |
QIP90 |
|
INSERT |
|
| DX0064 |
1.78 |
SDIP64 |
|
ZIF |
|
| DX0001 |
2.54 |
ZIF48 |
|
ZIF |
|
| BGA/PGA |
| Part
Number |
Pitch
(mm) |
Package |
Device
Example |
Type |
Price |
|
| CX5000 |
2.54 |
PGA121 |
|
ZIF |
|
| CX5001 |
0.8 |
BGA96 |
|
OPENTOP |
|
| CX5002 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5003 |
0.65 |
BGA137 |
|
OPENTOP |
|
| CX5004 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5005 |
0.8 |
BGA96 |
|
OPENTOP |
|
| CX5006 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5007 |
0.8 |
BGA72 |
|
OPENTOP |
|
| CX5008 |
0.8 |
BGA76 |
|
|
|
| CX5009 |
0.8 |
BGA99 |
|
OPENTOP |
|
| CX5010 |
0.8 |
BGA130 |
|
OPENTOP |
|
| CX5011 |
0.8 |
BGA137 |
|
OPENTOP |
|
| CX5012 |
0.8 |
BGA137 |
|
OPENTOP |
|
| CX5013 |
0.8 |
BGA140 |
|
OPENTOP |
|
| CX5014 |
0.75 |
BGA72 |
|
OPENTOP |
|
| CX5015 |
0.65 |
BGA129 |
|
OPENTOP |
|
| CX5016 |
0.65 |
BGA129 |
|
OPENTOP |
|
| CX5017 |
0.65 |
BGA225 |
|
OPENTOP |
|
| CX5018 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5019 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5020 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5021 |
1 |
BGA256 |
|
OPENTOP |
|
| CX5022 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5023 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5024 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5025 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5026 |
0.8 |
BGA72 |
|
OPENTOP |
|
| CX5027 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5028 |
0.8 |
BGA96 |
|
OPENTOP |
|
| CX5029 |
0.8 |
BGA96 |
|
OPENTOP |
|
| CX5030 |
0.8 |
BGA149 |
|
OPENTOP |
|
| CX5031 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5032 |
0.75 |
BGA56 |
|
OPENTOP |
|
| CX5033 |
0.75 |
BGA56 |
|
OPENTOP |
|
| CX5034 |
0.75 |
BGA56 |
|
OPENTOP |
|
| CX5035 |
0.75 |
BGA56 |
|
OPENTOP |
|
| CX5036 |
0.75 |
BGA63 |
|
OPENTOP |
|
| CX5037 |
0.5 |
BGA48 |
|
OPENTOP |
|
| CX5038 |
0.5 |
BGA48 |
|
OPENTOP |
|
| CX5039 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5040 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5041 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5042 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5043 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5044 |
0.8 |
BGA63 |
|
OPENTOP |
|
| CX5045 |
0.8 |
BGA56 |
|
OPENTOP |
|
| CX5046 |
0.8 |
BGA63 |
|
OPENTOP |
|
| CX5047 |
0.8 |
BGA63 |
|
OPENTOP |
|
| CX5048 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5049 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5050 |
0.8 |
BGA64 |
|
OPENTOP |
|
| CX5051 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5052 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5053 |
0.8 |
BGA88 |
|
OPENTOP |
|
| CX5054 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5055 |
0.8 |
BGA100 |
|
OPENTOP |
|
| CX5056 |
0.8 |
BGA108 |
|
OPENTOP |
|
| CX5057 |
0.8 |
BGA115 |
|
OPENTOP |
|
| CX5058 |
0.8 |
BGA121 |
|
COVER |
|
| CX5059 |
1 |
BGA100 |
|
OPENTOP |
|
| CX5060 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5061 |
0.8 |
BGA149 |
|
OPENTOP |
|
| CX5062 |
0.8 |
BGA63 |
|
OPENTOP |
|
| CX5063 |
0.8 |
BGA36 |
|
OPENTOP |
|
| CX5064 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5065 |
0.65 |
BGA140 |
|
OPENTOP |
|
| CX5066 |
0.5 |
BGA56 |
|
OPENTOP |
|
| CX5067 |
0.5 |
BGA44 |
|
OPENTOP |
|
| CX5068 |
0.5 |
BGA44 |
|
OPENTOP |
|
| CX5069 |
0.5 |
BGA132 |
|
OPENTOP |
|
| CX5070 |
0.8 |
BGA88 |
|
OPENTOP |
|
| CX5071 |
0.8 |
BGA81 |
|
OPENTOP |
|
| CX5072 |
0.8 |
BGA116 |
|
OPENTOP |
|
| CX5073 |
0.8 |
BGA164 |
|
OPENTOP |
|
| CX5074 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5075 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5076 |
0.8 |
BGA56 |
|
OPENTOP |
|
| CX5077 |
0.8 |
BGA107 |
|
OPENTOP |
|
| CX5078 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5079 |
0.8 |
BGA80 |
|
OPENTOP |
|
| CX5080 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5081 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5082 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5083 |
0.8 |
BGA48 |
|
OPENTOP |
|
| CX5084 |
0.8 |
BGA140 |
|
OPENTOP |
|
| CX5085 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5086 |
0.8 |
BGA137 |
|
OPENTOP |
|
| CX5087 |
0.65 |
BGA140 |
|
OPENTOP |
|
| CX5088 |
1 |
BGA80 |
|
- |
|
| CX5089 |
1 |
BGA81 |
|
- |
|
| CX5090 |
1 |
BGA121 |
|
- |
|
| CX5091 |
0.65 |
BGA64 |
|
OPENTOP |
|
| CX5092 |
0.65 |
BGA165 |
|
OPENTOP |
|
| CX5093 |
0.75 |
BGA56 |
|
OPENTOP |
|
| CX5094 |
0.5 |
BGA56 |
|
OPENTOP |
|
| CX5095 |
0.8 |
BGA140 |
|
OPENTOP |
|
| CX5096 |
0.75 |
BGA48 |
|
OPENTOP |
|
| CX5097 |
0.8 |
BGA167 |
|
OPENTOP |
|
| CX5098 |
0.5 |
BGA133 |
|
OPENTOP |
|
| CX5099 |
0.5 |
BGA44 |
|
OPENTOP |
|
| CX5100 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5101 |
0.65 |
BGA165 |
|
OPENTOP |
|
| CX5102 |
0.5 |
BGA64 |
|
OPENTOP |
|
| CX5103 |
1 |
BGA64 |
|
OPENTOP |
|
| CX5104 |
0.5 |
BGA153 |
|
OPENTOP |
|
| CX5105 |
0.65 |
BGA160 |
|
OPENTOP |
|
| CX5106 |
0.8 |
BGA100 |
|
|
|
| CX5107 |
0.8 |
BGA144 |
|
|
|
| CX5163 |
|
BGA176 |
|
|
|
| CX5112 |
|
BGA48 |
|
|
|
| CX5158 |
0.6 |
FBGA169 |
|
|
|
| EX5104-T001-S4 |
0.5 |
BGA153 |
|
OPENTOP |
|
| GX5104-T001 |
0.5 |
BGA153 |
|
|
|
| GX5104-T001-S4 |
0.5 |
BGA153 |
|
OPENTOP |
|
| GX5239-T001 |
- |
BGA153 |
|
- |
|
| GX5239-T003-S4 |
- |
BGA153 |
|
- |
|
| DX5021 |
1 |
BGA256 |
|
OPENTOP |
|
| QFP/PQFP |
| Part Number |
Pitch (mm) |
Package |
Device Example |
Type |
price |
|
| CX3001 |
0.8 |
QFP32 |
|
COVER |
|
| CX3002 |
0.8 |
QFP44 |
|
COVER |
|
| CX3003 |
0.8 |
TQFP44 |
|
COVER |
|
| CX3004 |
0.8 |
QFP44 |
|
COVER |
|
| CX3005 |
0.8 |
QFP44 |
|
OPENTOP |
|
| CX3006 |
0.8 |
QFP48 |
|
COVER |
|
| CX3007 |
0.5 |
QFP48 |
|
COVER |
|
| CX3008 |
0.65 |
QFP48 |
|
COVER |
|
| CX3009 |
0.65 |
QFP52 |
|
COVER |
|
| CX3010 |
0.65 |
TQFP52 |
|
COVER |
|
| CX3011 |
0.5 |
QFP64 |
|
COVER |
|
| CX3012 |
0.65 |
TQFP64 |
|
COVER |
|
| CX3013 |
0.8 |
QFP64 |
|
COVER |
|
| CX3014 |
0.8 |
QFP64 |
|
COVER |
|
| CX3015 |
1 |
QFP64 |
|
COVER |
|
| CX3016 |
0.5 |
QFP80 |
|
COVER |
|
| CX3017 |
0.65 |
QFP80 |
|
COVER |
|
| CX3018 |
0.65 |
QFP80 |
|
COVER |
|
| CX3019 |
0.8 |
QFP80 |
|
COVER |
|
| CX3020 |
0.8 |
PQFP80 |
|
COVER |
|
| CX3021 |
0.5 |
QFP100 |
|
COVER |
|
| CX3022 |
0.65 |
PQFP100 |
|
COVER |
|
| CX3023 |
0.65 |
QFP100 |
|
COVER |
|
| CX3024 |
0.65 |
QFP112 |
|
COVER |
|
| CX3025 |
0.65 |
QFP112 |
|
COVER |
|
| CX3026 |
0.65 |
QFP112 |
|
OPENTOP |
|
| CX3027 |
0.4 |
QFP120 |
|
COVER |
|
| CX3028 |
0.5 |
QFP120 |
|
COVER |
|
| CX3029 |
0.8 |
QFP120 |
|
COVER |
|
| CX3030 |
0.4 |
TQFP128 |
|
COVER |
|
| CX3031 |
0.5 |
QFP128 |
|
COVER |
|
| CX3032 |
0.5 |
QFP128 |
|
COVER |
|
| CX3033 |
0.8 |
QFP128 |
|
COVER |
|
| CX3034 |
0.4 |
QFP144 |
|
COVER |
|
| CX3035 |
0.5 |
QFP144 |
|
COVER |
|
| CX3036 |
0.65 |
QFP144 |
|
COVER |
|
| CX3037 |
0.5 |
QFP160 |
|
COVER |
|
| CX3038 |
0.65 |
QFP160 |
|
COVER |
|
| CX3039 |
0.5 |
QFP208 |
|
COVER |
|
| CX3040 |
0.5 |
TQFP208 |
|
COVER |
|
| CX3041 |
0.4 |
QFP144 |
|
OPENTOP |
|
| CX3042 |
0.8 |
QFP64 |
|
COVER |
|
| CX3043 |
0.5 |
QFP100 |
|
OPENTOP |
|
| CX3044 |
0.8 |
QFP64 |
|
OPENTOP |
|
| CX3045 |
0.65 |
PQFP100 |
|
COVER |
|
| CX3046 |
0.8 |
QFP44 |
|
OPENTOP |
|
| CX3047 |
0.5 |
QFP48 |
|
OPENTOP |
|
| CX3048 |
1 |
QFP52 |
|
COVER |
|
| CX3049 |
1 |
QFP64 |
|
OPENTOP |
|
| CX3050 |
0.8 |
QFP32 |
|
COVER |
|
| CX3051 |
0.5 |
QFP144 |
|
OPENTOP |
|
| CX3057 |
0.5 |
QFP64 |
|
OPENTOP |
|
| TA054-B006 |
0.5 |
QFP64 |
|
OPENTOP |
|
| TA081-B084 |
0.65 |
QFP160 |
|
COVER |
|
| TA083A-B084 |
0.5 |
QFP160 |
|
OPENTOP |
|
TA029-B006
|
0.5 |
QFP100/D48
|
|
CLAM SHELL |
|
| TA067-B006 |
0.5 |
QFP64 |
|
COVER |
|
| DX3011 |
0.5 |
QFP64 |
|
COVER |
|
| DX3043 |
0.5 |
QFP100 |
|
OPENTOP |
|
| DX3025 |
0.65 |
QFP112
|
|
COVER
|
|
| DX3021 |
0.5 |
QFP100
|
|
COVER
|
|
| GX |
| GX4005 |
- |
- |
|
- |
|
注：型番の後ろに、*印が付いている場合、PEPシリーズのアダプタが必要です。
|
Part #
|
Package
|
|
Pitch
(mm) |
Example Device
|
price
|
| PLCC (Auto
Eject Socket) |
| SA001A
|
PLCC20/20D |
9*9
|
1.27 |
Lattice 16V8, 16R4 |
|
| SA008A
|
PLCC28/28D |
11.5*11.5
|
1.27 |
27C128, PALCE22V10, 20V8
|
|
| SA015A1T
|
PLCC32/32D |
11.5*14.1
|
1.27 |
Atmel 27C010,29F040 |
|
| SA244
|
PLCC44/44D |
17.5*17.5
|
1.27 |
PSD311, 89C51, 27C1024,
MACH111, 7032 |
|
| S415T
* |
PLCC52/100D |
19.2*19.2
|
1.27 |
Motorola 68HC711E9 |
|
| S414T
* |
PLCC68/100D |
24.2*24.2
|
1.27 |
EP7064, PSD5XX, X9572,
87C552, 68HC711K4 |
|
| S416T
* |
PLCC84/100D |
29.3*29.3
|
1.27 |
EP7128, MACH435, X95108
|
|
| SA647-B5201
|
PLCC52/48D |
20*20
|
1.27 |
Intel 87C196JQ/JR/JT/JV
|
|
| SA648-B6801
|
PLCC68/40D |
24.2*24.2
|
1.27 |
Intel 87C196KB/KC/KD
|
|
| SA648-B6802
|
PLCC68/40D |
24.2*24.2
|
1.27 |
87C196KR/KQ/KT/KS/JR
|
|
| SA648-B6803
|
PLCC68/40D |
24.2*24.2
|
1.27 |
8796BH/JF, 8797BH/JF
|
|
| SA648-B6805
|
PLCC68/40D |
24.2*24.2
|
1.27 |
87C196CA |
|
| SA648-B6806
|
PLCC68/40D |
24.2*24.2
|
1.27 |
PHILIPS P87C552/554 |
|
| SA648-B6807
|
PLCC68/40D |
24.2*24.2
|
1.27 |
MICROCHIP16C923/4/5/6
|
|
| SA649
|
PLCC84/40D |
29.3*29.3
|
1.27 |
Intel 87C196MH/MC |
|
| SA649-B8401 |
PLCC84/40D |
29.3*29.3
|
1.27 |
Intel 87C196MC/MH |
|
| SA649-B8402 |
PLCC84/40D |
29.3*29.3
|
1.27 |
Renesas H64F3337Y-CP84
|
|
| PLCC (Covered
Socket) |
| SA413
|
PLCC28L/28D |
11.5*11.5
|
1.27 |
Specific : GAL20V8, PALCE22V10,
2732 |
|
| SA413A
|
PLCC28L/28D |
11.5*11.5
|
1.27 |
First pin (Middle of
the bottom) |
|
| SA412 |
PLCC32L/32D |
14.1*14.1
|
1.27 |
Specific : AMD 27C010,
29F040 |
|
| SA412A |
PLCC32L/32D |
14.1*14.1
|
1.27 |
First pin (Middle of
the right) |
|
| SA411 |
PLCC44L/44D |
17.5*17.5
|
1.27 |
89C52, PSD311, MACH110,
E7032, 27C1024 |
|
| SA411A |
PLCC44L/44D |
17.5*17.5
|
1.27 |
First pin (Middle of
the bottom) |
|
| S424 * |
PLCC52L/100D |
19.2*19.2
|
1.27 |
68HC711E9 |
|
| S425C * |
PLCC68L/100D |
24.2*24.2
|
1.27 |
EP7064, PSD5XX, X9572,
87C552, 68HC711K4 |
|
| S426 * |
PLCC84L/100D |
29.3*29.3
|
1.27 |
EP7128, MACH435, X95108
|
|
| QFP |
| SA021
|
QFP44/44D |
10*10
|
0.8 |
socket, Yamaichi IC51-0444-467
|
|
| SA245A
|
QFP44/44D |
10*10
|
0.8 |
ATMEL 89C51, Philips
PSD311 |
|
| SA245A-B4401 |
QFP44/44D |
10*10
|
0.8 |
PHILIPS 87C591 for SPZ/LX/280
|
|
| SA245A-B4402 |
QFP44/44D |
10*10
|
0.8 |
UNIVERSAL QFP44/D40 for
SPZ/LX/280 |
|
| SA245A-B4805 |
QFP44/44D |
10*10
|
0.8 |
UNIVERSAL QFP44/D40 for
SuperPro501S/500P |
|
| SA248
|
TQFP48/48D |
7*7
|
0.5 |
XICOR 76F128 |
|
| S417 * |
TQFP64/100D |
14*20
|
1 |
Obsolete |
|
| S427
* |
PQFP100/100D |
14*20
|
0.65 |
Toshiba 87PH75F/78F |
|
| S427A * |
QFP100/100D |
14*20
|
0.65 |
Toshiba 87PH75F/78F |
|
| S604
* |
TQFP100/100D |
14*14
|
0.5 |
EP7128QFP |
|
| S604B
* |
QFP80/100D |
12*12
|
0.5 |
PIC 18F8620/8720 |
|
| S608
* |
TQFP160/100D |
28*28
|
0.65 |
Specific: Altera EPM7192X/7256X
|
|
| S609
* |
TQFP160/80D |
28*28
|
0.65 |
Specific: Altera EPM7128X/7160X
|
|
| S610 |
PQFP160/28D |
28*28
|
0.65 |
Specific: Lattice MACH320
/ 384 / 512 |
|
| S611A
* |
PQFP80/80D |
14*20
|
0.8 |
Toshiba 87PH20F |
|
| S614 * |
PQFP80/80D |
14*20
|
0.8 |
|
|
| S615B
* |
PQFP80/80D |
14*14
|
0.65 |
SIEMENS SAB-C515C-8EM
|
|
| S616
* |
TQFP64/64D |
10*10
|
0.5 |
Toshiba 87PM412 |
|
| S618
* |
PQFP64/64D |
14*20
|
1 |
Toshiba 87PH20F |
|
| S621
* |
TQFP64/64D |
14*14
|
0.8 |
Toshiba 87PH00DF |
|
| S625A
* |
TQFP64/64D |
14*14
|
0.8 |
ATMEGA 103L |
|
| SA636
|
TQFP32/32D |
7*7
|
0.8 |
ATMEL 90S443 |
|
| S640B
* |
PQFP80/80D
|
12*12
|
0.5 |
PIC18F8620/8720, 87PP21DF
|
|
| SA662
* |
MQFP52/52D |
10*10
|
0.65 |
MC68HC908LJ12CFB |
|
| SA662-B042 * |
QFP52/52D |
10*10
|
0.65 |
ANALOG ADUC812 |
|
| SA663
|
TQFP32/32D |
7*7
|
0.8 |
Motorola MC68HC908JB18FA
|
|
| SA665T |
QFP100/40D |
14*14
|
0.5 |
HD64F3026-T100 |
|
| SA668-B050A |
QFP64/48D |
14*14
|
0.8 |
HD64F3687/3684 |
|
| SA671 |
QFP48/48D |
10*10
|
0.65 |
H64F3664 |
|
| SA673 |
QFP52/48D |
10*10
|
0.65 |
UPSD3212C |
|
| SA675 |
QFP44/44D |
10*10
|
0.8 |
Universal QFP44 |
|
| SA679 |
QFP44/44D |
14*14
|
0.8 |
|
|
| S680 * |
QFP64/100D |
12*12
|
0.65 |
Fujitsu UB95F108H |
|
| TA001 |
QFP100/40D |
14*14
|
0.5 |
HD64F3026-T100 |
|
| TA002 |
QFP100/40D |
14*14
|
0.5 |
HD64F3434/3436/3437 |
|
| TA003 |
QFP80/32D |
14*20
|
0.8 |
H8/38024F |
|
| TA004 |
QFP80/32D |
12*12
|
0.5 |
H8/38024F |
|
| TA005 |
QFP80/32D |
14*14
|
0.65 |
H8/38024F |
|
| TA006 |
QFP80/32D |
14*14
|
0.65 |
H8/38024F |
|
| TA007 |
QFP80/32D |
12*12
|
0.5 |
H8/38024F |
|
| TA008 |
QFP80/32D |
14*14
|
0.65 |
H8/38024F |
|
| TA010 |
QFP100/48D |
14*20
|
0.65 |
MX10F202FC |
|
| TA011 |
QFP64/20D |
14*14
|
0.8 |
MC68HC908AZ60/AB32/AS60
|
|
| TA012 |
PQFP100/48D |
14*20
|
0.65 |
M30624/626FHPFP |
|
| TA013
|
PQFP100/40D
|
14*14
|
0.5
|
M30624/626FHPGP
|
|
| TA014 |
QFP80/40D |
14*14
|
0.65 |
HD64F7046 |
|
| TA015A |
QFP80/24D |
14*14
|
0.65 |
Motorola 9S12 |
|
| TA016 |
TQFP100/36D |
14*14
|
0.5 |
TMP91PW12F |
|
| TA017A |
PQFP100/48D |
14*14
|
0.65 |
M30624/626FHPFP |
|
| TA018 |
QFP80/32D |
14*14
|
0.65 |
H64F3337Y-TFP80A |
|
| TA019 |
QFP80/32D |
14*14
|
0.5 |
H64F3337Y-TFP80C |
|
| SOP/SOIC
|
| SA023A
|
SOIC20/20D |
7.5*12.8
|
1.27 |
CATALYST 24WC64 |
|
| SA024
|
TSOP48/48D |
16*12.2
|
0.5 |
SHARP LH532GYE |
|
|
|
|
|
|
|
|
| SA026
|
TSOP24/24D |
7.7*15.3
|
0.65 |
ATMEL CATALYST 34C02
|
|
| S246A |
PSOP44/44D |
13
|
1.27 |
Obsolete |
|
| SA247
|
TSOP48/48D |
18.4*12.2
|
0.5 |
Intel 28F200 / 400 /
800, 29F100 / 200 / 400 |
|
| SA247A |
TSOP48/48D |
18.4
|
0.5 |
AMD29F400B |
|
| S403 |
TSOP44/48D |
18.4*10.2
|
0.8 |
|
|
| SA404 |
SOIC28/28D |
7.4*17.9
|
1.27 |
PIC16C5x, 89C2051, COP8Sx
|
|
| SA409T-B034
|
TSOP40/40D |
18.4*10.2
|
0.5 |
Intel 28F002 / 004 /
008 , 29F002 /004 / 008 , 29F080 |
|
| SA410T-B033
|
NTSOP32/32D |
8.2*18.3
|
0.5 |
INTEL 82808 FOR SP Z/LX/280..
|
|
| S421 * |
TSOP56/100D |
18.4*14
|
0.5 |
Obsolete, replaced with
SA0628 + B series |
|
| SA430T
|
SSOP28/28D |
8.2*11.8
|
0.55 |
ATMEL 28C64 |
|
| SA438T
|
SOP32/32D |
11.6
|
1.27 |
Winbond 29C020 |
|
| SA602
|
SOIC16/16D |
7.5*10.3
|
1.27 |
Xilinx XC17xx, Microchip
93Cxx |
|
| SA602A
|
SOP8/8D |
4*5
|
1.27 |
Xilinx XC17xx |
|
| SA603
|
SOIC32/32D |
11.6*20.2
|
1.27 |
ATMEL 27C010 /020
/ 040 |
|
| SA605 |
SOIC20/16D |
7.5*12.8
|
1.27 |
Specific : Microchip
24Cxx |
|
| SA605B |
SOIC8/8D |
4*5.2
|
1.27 |
Obsolete, replaced with
SA023A ,SA605A |
|
| SA620
|
TSOP32/32D-1 |
12.4*8.2
|
0.5 |
Specific : SONY 28F400
|
|
| SA622 |
SOIC20/20D |
7.5*12.8
|
1.27 |
Obsolete, replaced with
A023A |
|
| SA623
|
TSOP40/40D |
12.3*10
|
0.5 |
Macronix 26C1024 |
|
| SA626 |
SSOP28/28D |
5.3*10.2
|
0.65 |
MICROCHIP PIC16C54 |
|
| SA626A
|
SSOP32/32D |
5.3
|
0.65 |
ATMEL, Catalyst, Fairchild
|
|
| SA628-B011
|
TSOP56/48D |
18.4*14
|
0.5 |
INTEL 28F016 / 032SA
/ SV / XS |
|
| SA628-B012
|
TSOP56/48D |
18.4*14
|
0.5 |
INTEL 28F200BV |
|
| SA628-B014
|
TSOP56/48D
|
18.4*14
|
0.5 |
INTEL 28F800S3 |
|
| SA628-B017
|
TSOP56/48D |
18.4*14
|
0.5 |
Atmel AT49BV1604 |
|
| SA628-B018
|
TSOP56/48D |
18.4*14
|
0.5 |
INTEL 28F128 / 320 /
640J3A |
|
| SA628-B031
|
TSOP56/48D |
18.4*14
|
0.5 |
ST M58LW032A |
|
| SA628-B045
|
TSOP56/48D |
18.4*14
|
0.5 |
AM29LV640MH/L |
|
| SA628-B067 |
TSOP56/56D |
18.4*14
|
0.5 |
AM29LV256ML |
|
| SA628-B067A
|
TSOP56/48D |
18.4*14
|
0.5 |
SSTM58LW128A |
|
| SA629-B013
|
SSOP56/48D |
15.6
|
0.4 |
Intel 28F160S3 |
|
| SA629-B015
|
SSOP56/48D |
15.6
|
0.4 |
Intel 28F800F3 |
|
| SA629-B020
|
SSOP56/48D |
15.6
|
0.4 |
AMD Am29LV640 / 641D
|
|
| SA629-B022
|
SSOP56/48D |
15.6
|
0.4 |
AMD Am29BL162C |
|
| SA630
|
SOIC32/32D |
8.9
|
1.27 |
ATMEL 894D12 |
|
| SA631
|
SON46/46D |
9.6
|
0.4 |
Fujitsu 29LV800TA |
|
| SA633 |
TSOP48/48D |
18.4*12.2
|
0.5 |
SHARP LH532GTE |
|
| SA635
|
SOIC20/20D |
7.5*12.8
|
0.65 |
AT89C2051, LG97C2051
|
|
| SA637B
|
TSOP48/48D |
18.4*12
|
0.5 |
SHARP LRS1306 |
|
| SA638
|
PSOP44/44D |
16.3*28.4
|
1.27 |
AM29BL400B/800B |
|
| SA643 |
TSOP28/28D |
4.4
|
0.65 |
MSP430F122/123 |
|
| SA645
|
TSOP54/48D |
10.16
|
0.8 |
CYPRESS CY7C1021, IDT71016
|
|
| SA645-B035
|
TSOP54/48D |
10.16
|
0.8 |
Micron MT28S4M16LC |
|
| SA646
|
SOJ32/32D |
7.6*26
|
1.27 |
CYPRESS CY7C199 |
|
| SA654
|
SOP16/16D |
6.2*6.2
|
1.27 |
SANYO LE25FV101T/201T
|
|
| SA657
|
TSOP52/48D |
10.8*8.9
|
0.4 |
Mitsubishi M6MGT321S4TP
|
|
| SA657-B036
|
TSOP52/48D |
8.89
|
0.4 |
Mitsubishi M6MGE157S4KT
|
|
| SA657-B055
|
TSOP52/48D |
8.89
|
0.4 |
Mitsubishi M6MGE157S4KT
|
|
| SA658 |
SSOP34 |
18.6*10.4
|
1 |
ST72T631K4M1 |
|
| SA661 |
SOJ44/44D |
10.9
|
1.27 |
OKI R27V852D |
|
| SA666 |
MSOP8 |
4.9*3.0
|
0.65 |
Xicor X5043/5045 |
|
| SA669 |
SSOP48/48D |
16*10.16
|
0.65 |
CY7C63412 |
|
| DIP/SDIP
|
| A025 |
SDIP24/24D |
6.4*23
|
1.78 |
SAMSUNG S3C9414 |
|
| A022A |
SDIP28/28D |
14.8
|
1.78 |
Toshiba 47P241VN-528
|
|
| A028
|
SDIP42/42D |
14.8
|
1.78 |
TOSHIBA/87 |
|
| S400 |
DIP48/48D |
14.8
|
2.54 |
Standard Socket for Superpro680
|
|
| S600*
|
SDIP64/100D |
14.8
|
1.78 |
Intel 87C196MC |
|
| A641
|
SDIP30/30D |
13.9
|
1.78 |
GMS81504T, AT49F8192
|
|
| S627*
|
SDIP56/56D |
14.8
|
1.78 |
Infineon SAB-C540U-1EP
/ C541U-1EP |
|
| A651
|
SDIP64/40D |
14.8
|
1.78 |
Specific : Intel 87C196MH
/ MC |
|
| SA752+B265 |
SDIP64/D48 |
20.7 |
1.778 |
|
|
| SA736-B229 |
SDIP64 |
|
|
|
|
| BGA
|
| A634
|
uBGA48/48 |
7.58*9.81
|
0.75 |
Flash INTEL 28F160B3
/ 320B3 |
|
| A644-25
|
uBGA96/48D |
7.7*9
|
0.75 |
Intel RD28F320W18 |
|
| A644-28
|
uBGA96/48D |
7.7*9
|
0.75 |
Intel 28F320 / 640J5
|
|
| A642-23
|
BGA96/48D |
8*12
|
0.8 |
RD28F1602 / 3204C3 |
|
| A642-24
|
BGA96/48D |
8*12
|
0.8 |
FUJITSU MB84VD2218XA
|
|
| A642-25
|
BGA96/48D |
8*12
|
0.8 |
MT28C2112P2FL |
|
| A642-26
|
BGA96/48D |
8*12
|
0.8 |
AMD AM29DL322 / 323C
|
|
| A642-29
|
BGA96/48D |
8*12
|
0.8 |
SHARP LH28F640BFHP |
|
| A642-30
|
BGA96/48D |
8*12
|
0.8 |
Micron MT28C6428P20T/B
|
|
| A642-32
|
BGA96/48D |
8*12
|
0.8 |
AMD AM41DL6408G |
|
| A642-39
|
BGA96/48D |
8*12
|
0.8 |
AMD AM50DL128G |
|
| A642-41A
|
BGA96/48D |
8*12
|
0.8 |
Intel RD28F6408 / 1604
/ 3408J3A |
|
| A642-43
|
BGA96/48D |
8*12
|
0.8 |
AMD AM29BDS640G |
|
| A642-52
|
BGA96/48D |
8*12
|
0.8 |
SHARP LRS1826A / 1829
|
|
| A642A-68
|
BGA48 |
4*5.6
|
0.8 |
Xilinx X9572/36XL / XV
|
|
| A655-27
|
BGA96/48D |
10*13
|
1 |
Intel 28F320 / 640J3A
|
|
| A655-37
|
BGA96/48D |
10*13
|
1 |
Intel RC28F160 / 320
/ 128C3 |
|
| A655-38
|
BGA96/48D |
10*13
|
1 |
AMD AM29LV642D |
|
| A655-40
|
BGA96/48D |
|
1 |
AMD AM29DL640G |
|
| A655-44
|
BGA96/48D |
10*13
|
1 |
AMD AM29LV641MH |
|
| PGA
|
| 612A*
|
PGA68/68D |
28*28
|
2.5 |
INTEL 87C196MC |
|
| 612A-04 |
PGA68/40D |
28*28
|
2.5 |
INTEL 8797BH/JF |
|
| A667 |
PGA121/121D |
|
2.54 |
ACT F512K32 |
|
| MLF
(QFN) |
| SA683 |
QFN8/D8 |
6.0*5.0
|
1.27
|
|
|
| SA670 |
MLF44 |
7*7
|
0.5
|
Atmega 16-16MC |
|
| SA692 |
QFN20/D20
|
4*4
|
0.5
|
|
|
| SA694-B8404 |
QFN8 |
3*2
|
0.5
|
|
|
| SA697-B006 |
QFN28/D28 |
5*5
|
0.5
|
|
|
| PEP
|
| PEP |
PEP100 |
|
|
100Pins Expander for
Superpro III(Obsolete) |
|
| PEP |
PEP500 |
|
|
100Pins Expander for
Superpro V(Obsolete) |
|
| PEP |
PEP600 |
|
|
100 Pins Expander for
Superpro 680 |
|
| PEP |
PEP3000 |
|
|
100 Pins Expander for
Superpro 3000U |
|
| ISP |
| ISP-HEADER01 |
|
|
|
|
|
注：型番の後ろに、*印が付いている場合、PEPシリーズのアダプタが必要です。
Part # |
Package |
W*L |
Pitch |
Example Device |
price |
| PLCC |
| SA001A |
PLCC20/20D |
9*9 |
1.27 |
Lattice 16V8,18CV8,16L8 |
|
| A017 |
PLCC28/28D |
11.5*11.5 |
1.27 |
same as A008 |
|
| A019 |
PLCC28/24D-2 |
11.5*11.5 |
1.27 |
Specific : 2716,2732 |
|
| A018 |
PLCC28/28D-1 |
11.5*11.5 |
1.27 |
Specific : Lattice GAL20V8, 22V10 |
|
| A002 |
PLCC32/28D |
11.5*14.1 |
1.27 |
Specific:28-EPROM(2764,7128,27256,27512) |
|
| A003 |
PLCC32/32D |
11.5*14.1 |
1.27 |
32 PIN E(E)PROM(27010, 27020, 27040, 27080,27280, 28F256, 8F512, 28F010, 29C256, 29010, 29040) |
|
| A004 |
PLCC44/40D-1 |
17.5*17.5 |
1.27 |
Specific : Philips 87C5X MCUs |
|
| A005 |
PLCC44/40D-2 |
17.5*17.5 |
1.27 |
Specific : Macronix 27C1024 EPROMs |
|
| A102 |
PLCC44/32D |
17.5*17.5 |
1.27 |
Specific : Philips PSD3XX |
|
| A204 |
PLCC68/40D |
25*25 |
1.27 |
Specific : Philips PSD4XX / 5XX |
|
| A647-01 |
PLCC52/48D |
20*20 |
1.27 |
Intel 87C196JQ / JR / JT / JV |
|
| A648-01 |
PLCC68/40D |
24.2*24.2 |
1.27 |
Intel 87C196KB / KC / KD |
|
| A648-02 |
PLCC68/40D |
24.2*24.2 |
1.27 |
Intel 87C196KR / KQ / KT / KS / JR |
|
| A648-03 |
PLCC68/40D |
24.2*24.2 |
1.27 |
8796BH/JF, 8797BH / JF |
|
| A648-05 |
PLCC68/40D |
24.2*24.2 |
1.27 |
87C196CA |
|
| A648-06 |
PLCC68/40D |
24.2*24.2 |
1.27 |
Philips 87C552 |
|
| A649-01 |
PLCC84/40D |
29.3*29.3 |
1.27 |
Intel 87C196MH / MC |
|
| QFP |
| SA675-B4402 |
QFP44/44D |
10*10 |
0.8 |
Universal QFP44 |
|
| A021 |
QFP44/40D |
10*10 |
0.8 |
Specific : NEC Devices |
|
| A011 |
QFP44/40D-1 |
10*10 |
0.8 |
Specific : Philips 89C5X, 87C5X |
|
| SOP/SOIC |
| SA638 |
PSOP44/44D |
13 |
1.27 |
AMD Am29BL400B/800B |
|
| SA605B |
SOIC8/8D |
5.2 |
1.27 |
Obsolete, replaced with
SA023A ,SA605A |
|
| A012 |
SOIC16/16D |
4 |
1.27 |
Xilinx XC17XXX |
|
| SA602 |
SOIC16/16D |
7.5*10.3 |
1.27 |
Xilinx XC17xx,Microchip 93Cxx |
|
| A013 |
SOIC20/16D |
5.3 |
1.27 |
Specific : Microchip 24CX |
|
| SA605 |
SOIC20/16D |
7.5*12.8 |
1.27 |
Specific : Microchip 24Cxx |
|
| A023A |
SOIC20/20D |
5.3 |
1.27 |
Catalyst |
|
| A404 |
SOIC20/20D |
7.8 |
1.27 |
PIC16C5x, 89C2051, COP8Sx |
|
| A635 |
SOIC20/20D |
4.4*6.5 |
0.65 |
AT89C2051, LG97C2051 |
|
| A014 |
SOIC28/28D |
7.5 |
1.27 |
AT89C2051, PIC16C54, COPXXX |
|
| SA603 |
SOIC32/32D |
11.6*20.2 |
1.27 |
ATMEL 27C010/020/040 |
|
| SA630 |
SOIC32/32D |
8.9 |
1.27 |
ATMEL 894D12 |
|
| SA602A |
SOP8/8D |
4 |
1.27 |
Xilinx XC17xx |
|
| A015 |
SOP32/32D |
|
|
|
|
| SA438T |
SOP32/32D |
11.6 |
1.27 |
Winbond 29C020 |
|
| A018A |
SSOP28/28D |
5.3 |
0.65 |
Microchip 28C64 |
|
| A430 |
SSOP28/28D |
8.2*11.8 |
0.55 |
Atmel 28C64 |
|
| SA626A |
SSOP32/32D |
5.3 |
0.65 |
ATMEL, Catalyst 34W02 |
|
| SA626 |
TSOP28/28D |
5.3 |
0.65 |
ATMEL, Catalyst 34W02 |
|
| A410 |
TSOP32/32D |
8.2*18.3 |
0.5 |
Atmel 27C010 |
|
| SA620 |
TSOP32/32D-1 |
12.4*8.2 |
0.5 |
Specific : SONY 28F400 |
|
| A621 |
TSOP32/32D |
20.2*8.1 |
0.5 |
ATMEL AT49F001NT |
|
| A409 |
TSOP40/40D |
18.4*10.2 |
0.5 |
Intel 28F002/004/008, 29F002/004/008 |
|
| SA623 |
TSOP40/40D |
12.3*10 |
0.5 |
Macronix 26C1024 |
|
| A007 |
TSOP40/40D-1T |
10 |
0.5 |
Specific : TSOP40 FLASH |
|
| A008 |
TSOP48/40D-3T |
12 |
0.5 |
Specific : TSOP48 FLASH |
|
| A247 |
TSOP48/48D |
12.2*18.4 |
0.5 |
Intel 28F200 / 400 / 800, 29F100 / 200 / 400 |
|
| DIP |
| A010 |
DIP32/20D |
8.4 |
1.78 |
Specific : 97CX051 in DIP20 |
|
| A101B |
DIP40/32D |
14 |
2.5 |
Specific : ATMEL AT89C5X |
|
|
